SGW2A47FF3 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. SGW2A47FF3

Part No. SGW2A47FF3
Supplier Merck KGaA

Optiscale® Capsule Polysep® II 1.0/1.2 µm 3/4 in. TC/TC

Net Price

112

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Catalogue Number

SGW2A47FF3
Chemistry

Borosilicate Glass Fiber (BGF) and Mixed Cellulose Esters (MCE)
Device Configuration

Capsule
Device Material

Polycarbonate
Diameter

6.9 cm (2.7 in.)
Filtration Area

17.7 cm²
Format

Double Layer
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Sanitary Flange
Inlet Connection Diameter

3/4 in.
Material Size

3
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

5.5 bar (80 psi) @ 25 °C
Maximum Inlet Temperature

25 °C
Media

Polysep™ II
Nominal Pore Size

1.0 / 1.2 µm
Outlet Connection

Sanitary Flange
Outlet Connection Diameter

3/4 in.
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥100 mL
Pore Size

1.0 / 1.2 µm
Seal Material

Fluoroelastomer (FKM)
Sterilization

3 autoclave cycles of 60 min @ 121 °C; not in-line steam sterilizable
Support Material

Polypropylene
Trade Name

OptiScale®
Vent Cap Material

Polyvinylidene fluoride (PVDF)
