SHVEA47FH3 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. SHVEA47FH3

Part No. SHVEA47FH3
Supplier Merck KGaA

Optiscale® 47mm Millipore Express® SHR 0.5/0.1 µm 3/4 in. TC-1/4 in. HB

Net Price

119

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Cartridge Nominal Length

3.24 in. (82 mm)
Catalogue Number

SHVEA47FH3
Chemistry

Polyethersulfone (PES)
Device Configuration

Capsule
Device Material

Polycarbonate
Diameter

6.9 cm (2.7 in.)
Filtration Area

17.7 cm²
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Sanitary Flange
Inlet Connection Diameter

3/4 in.
Length

3.24 in. (82 mm)
Material Size

3
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

5.5 bar (80 psi) @ 25 °C
Maximum Inlet Temperature

25 °C
Media

Millipore Express® SHR w/Prefilter
Outlet Connection

Hose Barb
Outlet Connection Diameter

1/4 in.
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥100 mL
Pore Size

0.5 / 0.1 µm
Seal Material

Fluoroelastomer (FKM)
Sterilization

3 autoclave cycles of 60 min @ 126 °C
Support Material

Polypropylene
Trade Name

Millipore Express®
Vent Cap Material

Polyvinylidene fluoride (PVDF)
Wettability

Hydrophilic
