Bacterial Endotoxins
Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
-
Catalogue Number
SGW3A47FF3
-
Chemistry
Borosilicate Glass Fiber (BGF) and Mixed Cellulose Esters (MCE)
-
Device Configuration
Capsule
-
Device Material
Polycarbonate
-
Diameter
6.9 cm (2.7 in.)
-
Filtration Area
17.7 cm²
-
Good Manufacturing Practices
These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
-
Indirect Food Additive
All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
-
Inlet Connection
Sanitary Flange
-
Inlet Connection Diameter
3/4 in.
-
Material Size
3
-
Maximum Inlet Pressure (psig)
80 psig
-
Maximum Inlet Pressure, bar (psi)
5.5 bar (80 psi) @ 25 °C
-
Maximum Inlet Temperature
25 °C
-
Media
Polysep™ II
-
Nominal Pore Size
1.0 / 0.2 µm
-
Outlet Connection
Sanitary Flange
-
Outlet Connection Diameter
3/4 in.
-
Oxidizable Substances
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥100 mL
-
Pore Size
1.0 / 0.2 µm
-
Seal Material
Fluoroelastomer (FKM)
-
Sterilization
3 autoclave cycles of 60 min @ 121 °C; not in-line steam sterilizable
-
Support Material
Polypropylene
-
Trade Name
OptiScale®
-
Vent Cap Material
Polyvinylidene fluoride (PVDF)
