CN1H71E06 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. CN1H71E06

Part No. CN1H71E06
Supplier Merck KGaA

Polygard-CN Cartridge Filter 10 in. 10.0 µm Code 7 Ethylene-Propylene

Net Price

562

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Cartridge Code

Code 7 (2-226) O-rings w/locking-tabs
Cartridge Nominal Length

10 in. (25 cm)
Catalogue Number

CN1H71E06
Chemistry

Polypropylene (PP)
Device Configuration

Cartridge
Device Material

Polypropylene
Diameter

7.0 cm (2.75 in.)
Filtration Area

0.42 m²
Gravimetric Extractables

≤50 mg after 24-h soak in water
Length

10 in. (25 cm)
Material Size

6
Maximum Differential Pressure, bar (psid)

4.8 bar (70 psid) @ 25 °C
Maximum Inlet Pressure, bar (psi)

4.8 bar (70 psi) @ 25 °C
Nominal Pore Size

10.0 µm
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥5 L
Pore Size

10.0 µm
Sanitization

30 min with hot water @ 80 °C
Seal Material

Ethylene Propylene
Sterilization

10 autoclave cycles or SIP @ 126 °C for 30 min
Trade Name

Polygard®
Wettability

Hydrophilic
