Bacterial Endotoxins
Aqueous extraction contains ≤0.5 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
-
Bacterial Retention
Quantitative retention of 107 CFU/cm2 Brevundimonas diminuta (ATCC® 19146) per ASTM® F838-83 methodology
-
Catalogue Number
SI1M142A7
-
Chemistry
Polyvinylidene Fluoride (PVDF)
-
Device Configuration
Capsule
-
Device Material
Polycarbonate
-
Diameter
6.9 cm (2.7 in.)
-
Filtration Area
100 cm²
-
Flow Rate
1.5 L/min @ 1.75 bar ΔP
-
Inlet Connection
Hose Barb
-
Inlet Connection Diameter
1/4 in.
-
Length
9.4 cm
-
Material Size
1
-
Maximum Differential Pressure, bar (psid)
Forward: 4.1 bar (60 psid) @ 25 °C; 1.7 bar (25 psid) @ 80 °C; 0.35 bar (5 psid) @ 123 °C; Reverse: 0.7 bar (10 psid) @ 25 °C
-
Maximum Inlet Pressure, bar (psi)
5.2 bar (75 psi) @ 25 °C
-
Media
Durapore®
-
Outlet Connection
Hose Barb
-
Outlet Connection Diameter
1/4 in.
-
Oxidizable Substances
Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥200 mL
-
Pore Size
0.22 µm
-
Process Volume
10 L
-
Sterility
Other
-
Sterilization
3 autoclave cycles of 90 min @ 123 °C; not in-line steam sterilizable
-
Support Material
Polycarbonate
-
Trade Name
Millipak®
-
Vent Cap Material
Polyvinylidene fluoride (PVDF)
-
Volume
10 L
-
Wettability
Hydrophilic
