PXB005A50 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. PXB005A50

Part No. PXB005A50
Supplier Merck KGaA

Pellicon® XL50 with Biomax® 5 kDa Membrane, A screen, 50 cm²

Net Price

232

Availability

4 weeks

PROPERTIES

Catalogue Number

PXB005A50
Chemistry

Polyethersulfone (PES)
Device Configuration

Cassette
Device Material

Polypropylene
Filter Code

Biomax 5
Filter Type

Ultrafiltration
Filtration Area

50 cm²
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Gravimetric Extractables

The extractables level was equal to or less than 7.5 mg per device after a water flush
Hold-up Volume

3.2 mL
Key Applications

Protein PurificationAnalytical Sample Prep
Length

18.8 cm (7.4 in.)
Material Package

Each Pellicon® XL50 cassette is packaged one per box and includes Operating Instructions, an Accessory Kit and a Certificate of Quality
Material Size

1
Maximum Inlet Pressure, bar (psi)

5.5 bar (80 psi) @ 50 °C
Maximum Transmembrane Pressure

2.8 bar (40 psig)
Media

Biomax®
Membrane Area

50 cm²
Minimum Working Volume

15 mL
NMWL

5 kDa
pH Range

pH1 – pH14 continuous; pH1 – pH14 cleaning
Recirculation Rate

0.03–0.05 L/min
Screen Material

Polypropylene, Thermoplastic Elastomer
Screen Type

Type A screen (tight screen)
Trade Name

Pellicon®
Volume

3.2 mL
Width

3 cm (1.2 in.)
