KVEPA10TH1 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. KVEPA10TH1

Part No. KVEPA10TH1
Supplier Merck KGaA

Autoclavable Opticap® XL 10 Millipore Express® SHR single layer 0.1 µm 1-1/2 in. TC-9/16 in. HB

Net Price

410

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Bacterial Retention

Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
Cartridge Nominal Length

10 in. (25 cm)
Catalogue Number

KVEPA10TH1
Chemistry

Polyethersulfone (PES)
Device Configuration

Capsule
Device Material

Polypropylene
Device Size

10 in.
Diameter

10.7 cm (4.2 in.)
European Pressure Equipment Directive

EMD Millipore Corporation® certifies that this product complies with the European Pressure Equipment Directive, 97/23/EC of 29 May 1997. This product has been classified under Article 3 § 3 of the Pressure Vessel Directive. It has been designed and manufactured in accordance with sound engineering practice to ensure safe use. In compliance with Article 3 § 3 of this Pressure Vessel Directive, this product does not bear the CE mark.
Filtration Area

0.6 m²
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Housing Material

Polypropylene (PP)
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Sanitary Flange
Inlet Connection Diameter

1-1/2 in.
Inlet to Outlet Width

33.5 cm (13.2 in.)
Length

10 in. (25 cm)
Material Package

Double Easy-Open bag
Material Size

1
Maximum Differential Pressure

80 psi (5.5 bar) continuous100 psi (6.9 bar) intermittent
Maximum Differential Pressure, bar (psid)

Forward: 6.9 bar (100 psid) intermittent @ 25 °C; 5.5 bar (80 psid) @ 25 °C; 1.0 bar (15 psid) @ 80 °C. Reverse: 2.1 bar (30 psid) @ 25 °C, intermittent
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

6.9 bar (100 psi) intermittent @ 23 °C; 5.5 bar (80 psi) @ 23 °C; 2.75 bar (40 psi) @ 60 °C; 1.0 bar (15 psi) @ 80 °C
Maximum Inlet Temperature

25 °C
Media

Millipore Express® SHR
Non-Fiber Releasing

This product was manufactured with a Millipore Express® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection

Hose Barb
Outlet Connection Diameter

9/16 in.
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥1 L
Pore Size

0.1 µm
Seal Material

Silicone (SI)
Sterilization

3 autoclave cycles of 60 min @ 126 °C; not in-line steam sterilizable
Support Material

Polypropylene
Trade Name

Millipore Express®
USP Bacterial Endotoxins

A sample aqueous extraction contains less than 0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Vent Cap Material

Polypropylene (PP)
Wettability

Hydrophilic
Width

33.5 cm (13.2 in.)

DESCRIPTION

Genuine product
