KHGES3FTT1 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. KHGES3FTT1

Part No. KHGES3FTT1
Supplier Merck KGaA

Sterile Opticap® XLT 30 Millipore Express® SHC 0.5/0.2 µm TC/TC 1pk w/3/4" TC top

Net Price

1255

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Bacterial Retention

Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
Cartridge Nominal Length

30 in. (75 cm)
Catalogue Number

KHGES3FTT1
Chemistry

Polyethersulfone (PES)
Device Configuration

Capsule
Device Material

Polypropylene/Polysulfone
Device Size

30 in.
Diameter

19.8 cm (7.8 in.)
Filtration Area

1.63 m²
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Housing Material

Polypropylene (PP)
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Sanitary Flange
Inlet Connection Diameter

1-1/2 in.
Length

30 in. (75 cm)
Material Package

Double Easy-Open bag
Material Size

1
Maximum Differential Pressure

Forward: 5500 mbar (80 psi) @ 25 °C; 1000 bar (15 psi) @ 80 °C; 6900 mbar (100 psi) @ 25 °C, intermittent. Reverse: 2100 bar (30 psi) @ 25 °C, intermittent
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

6.9 bar (100 psi) intermittent @ 25 °C; 5.5 bar (80 psi) @ 25 °C; 2.75 bar (40 psi) @ 60 °C; 1.0 bar (15 psi) @ 80 °C
Maximum Inlet Temperature

25 °C
Media

Millipore Express® SHC
Non-Fiber Releasing

This product was manufactured with a Millipore Express® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection

Sanitary Flange
Outlet Connection Diameter

1-1/2 in.
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥6 L
Pore Size

0.5 / 0.2 µm
Seal Material

Silicone (SI)
Sterility

Sterile
Sterilization

3 autoclave cycles of 60 min @ 126 °C; capable of 45 kilogray (4.5 Megarad) gamma exposure; not in-line steam sterilizable
Support Material

Polyester
Trade Name

Millipore Express®
USP Bacterial Endotoxins

A sample aqueous extraction contains less than 0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Vent Cap Material

Polypropylene (PP)
Wettability

Hydrophilic

DESCRIPTION

Genuine product
