KVEPG3THH1 - Merck - Filters and Filtration - Chromatography - Lab supplies

: Catalog No. KVEPG3THH1

Part No. KVEPG3THH1
Supplier Merck KGaA

Opticap® Gamma Compatible XLT 30 Millipore Express® SHR single layer 0.1 µm 5/8 in. HB/HB without gauge port

Net Price

1369

Availability

4 weeks

PROPERTIES

Bacterial Endotoxins

Aqueous extraction contains ≤0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) Test
Bacterial Retention

Samples were quantitatively retentive of a minimum Brevundimonas diminuta challenge concentration of 1 x 10⁷ CFU/cm² using ASTM® F838 methodology.
Cartridge Nominal Length

30 in. (75 cm)
Catalogue Number

KVEPG3THH1
Chemistry

Polyethersulfone (PES)
Device Configuration

Capsule
Device Material

Polypropylene
Device Size

30 in.
Diameter

10.7 cm (4.2 in.)
Filtration Area

2.06 m²
Good Manufacturing Practices

These products are manufactured in a facility which adheres to FDA Good Manufacturing Practices.
Housing Material

Polypropylene (PP)
Indirect Food Additive

All component materials meet the FDA Indirect Food Additive requirements cited in 21 CFR 177-182.
Inlet Connection

Hose Barb
Inlet Connection Diameter

5/8 in.
Inlet to Outlet Width

19.8 cm (7.4 in.)
Length

30 in. (75 cm)
Material Package

Double Easy-Open bag
Material Size

1
Maximum Differential Pressure

80 psi (5.5 bar) continuous100 psi (6.9 bar) intermittent
Maximum Differential Pressure, bar (psid)

Forward: 6.9 bar (100 psid) intermittent @ 25 °C; 5.5 bar (80 psid) @ 25 °C; 1.0 bar (15 psid) @ 80 °C. Reverse: 2.1 bar (30 psid) @ 25 °C, intermittent
Maximum Inlet Pressure (psig)

80 psig
Maximum Inlet Pressure, bar (psi)

6.9 bar (100 psi) intermittent @ 23 °C; 5.5 bar (80 psi) @ 23 °C; 2.75 bar (40 psi) @ 60 °C; 1.0 bar (15 psi) @ 80 °C
Maximum Inlet Temperature

25 °C
Media

Millipore Express® SHR
Non-Fiber Releasing

This product was manufactured with a Millipore Express® membrane which meets the criteria for a "non-fiber releasing" filter as defined in 21 CFR 210.3 (b) (6).
Outlet Connection

Hose Barb
Outlet Connection Diameter

5/8 in.
Oxidizable Substances

Will meet the USP Oxidizable Substances Test requirements after a water flush of ≥4.5 L
Pore Size

0.1 µm
Seal Material

Silicone (SI)
Sterility

Gamma
Sterilization

Gamma Compatible to 45 kGy. May be autoclaved for 3 cycles of 60 min @ 123 °C; not in-line steam sterilizable
Support Material

Polyester
Trade Name

Millipore Express®
USP Bacterial Endotoxins

A sample aqueous extraction contains less than 0.25 EU/mL as determined by the Limulus Amebocyte Lysate (LAL) test.
Vent Cap Material

Polypropylene (PP)
Wettability

Hydrophilic
Width

19.8 cm (7.4 in.)

DESCRIPTION

Genuine product
