Catalog No. SVHVL10RC
Part No. SVHVL10RC
Supplier Merck KGaA
Sterivex-HV Pressure Filter Unit
Net Price
115
Availability

4 weeks

PROPERTIES
  • Background Information
    - Sterivex filter units work with syringes, peristaltic pumps or pressure vessels. They eliminate the risk of contamination associated with decanting or pipetting. - Sterivex units are designed to dispense into virtually any storage container. The devices are available with different outlet connections (see table). - Sterivex filter units can process volumes up to 1,000 mL or 2,000 mL, depending on the type of membrane used in the device. A choice of three different membranes is provided. - Filter-sterilize volumes up to 1,000 mL or 2,000 mL, using Sterivex™ pressure-driven filter units (capacity depends on the type of membrane used in the device). With three different membrane options and a variety of outlet connection options, Sterivex™ filters can fit virtually any workflow and dispense into nearly any storage container. Sterivex™ filters work with syringes, peristaltic pumps or pressure vessels and eliminate the risk of contamination associated with decanting or pipetting.Features & Benefits: - Works with a variety of pressure devices including syringes, perstaltic pumps and pressure vessels - Comes in multiple membrane types to suit your application needs with capacities up to 2 L Applications:Sterilization of Aqueous Solutions
  • Catalogue Number
    SVHVL10RC
  • Chemistry
    Hydrophilic Polyvinylidene Fluoride (PVDF)
  • Color Code
    Clear
  • Device Material
    Eastar®
  • Diameter
    1.7 cm
  • Filtration Area
    10 cm²
  • Fitting Inlet
    Female Luer-Lok® with upstream vent
  • Fitting Outlet
    Male Luer-Lok®
  • Height
    82 mm
  • Hold-up Volume
    2.2 mL
  • Key Applications
    Sterile Filtration
  • Material Size
    15
  • Maximum Inlet Pressure, bar (psi)
    3.1 bar (45 psi)
  • Maximum Operating Temperature
    45 °C
  • Media
    Durapore®
  • Nominal Pore Size
    0.45 µm
  • Pore Size
    0.45 µm
  • Process Volume
    1000 mL
  • Sterility
    Sterile
  • Sterilization
    Gamma irradiation
  • Trade Name
    Sterivex
  • Volume
    2.2 mL
  • Wettability
    Hydrophilic
DESCRIPTION
0.45 µm pore size, PVDF membrane, with Luer outlet, gamma irradiated, sterile
