By using CHROMAFIL filtration products (syringe filters, filtration cartridges, 96-well plates) unwanted particles are removed which can otherwise cause contamination and clogging of sensitive instrumentation. So, filtering your samples leads to an increase of lifetime and less downtime of chromatographic columns and equipment as well as gives more consistent and reproducible results. Inside the filter products are membranes with hydrophilic or hydrophobic properties. For example the hydrophilic multipurpose PET membrane is suitable for polar as well as nonpolar solvents. MACHEREY‑NAGEL offers a wide selection of membranes in syringe filters. CHROMAFIL Xtra are syringe filters that are labeled for method validation and certification. Filtration cartridges are supplied with regenerated cellulose, glass fiber, polytetrafluoroethylene, polyester (polyethylene terephthalate) as well as with polyvinylidene difluoride membrane in different pore sizes and cartridge volumes. CHROMAFIL 96‑well polypropylene plates with different membrane types for simultaneous filtration of 96 samples are also available.

Catalog No.		Product	Net Price
	MN729030	Syringe filters, color coded, CHROMAFIL RC, 25 mm, 0.2 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Hardware Polypropylene (PP) housing with filter membrane Selling unit 100 pieces, 400 pieces Recommended application(s) Suitable for aqueous, polar, hydrophilic as well as mid-polar samples with low particle-load, Suitable for UHPLC, core-shell and HPLC columns packed with particles > 3 µm, GC, SFC Storage temperature RT
	MN729031	Syringe filters, color coded, CHROMAFIL RC, 25 mm, 0.45 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Hardware Polypropylene (PP) housing with filter membrane Selling unit 100 pieces, 400 pieces Recommended application(s) General purpose HPLC columns packed with particles > 3 µm, GC, SFC, Suitable for aqueous, polar, hydrophilic as well as mid-polar samples with low particle-load Storage temperature RT
	MN729036	Syringe filters, color coded, CHROMAFIL RC, 15 mm, 0.2 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Hardware Polypropylene (PP) housing with filter membrane Recommended application(s) Suitable for aqueous, polar, hydrophilic as well as mid-polar samples with low particle-load, Suitable for UHPLC, core-shell and HPLC columns packed with particles > 3 µm, GC, SFC Storage temperature RT
	MN729037	Syringe filters, color coded, CHROMAFIL RC, 15 mm, 0.45 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Hardware Polypropylene (PP) housing with filter membrane Recommended application(s) General purpose HPLC columns packed with particles > 3 µm, GC, SFC, Suitable for aqueous, polar, hydrophilic as well as mid-polar samples with low particle-load Storage temperature RT
	MN729230	Syringe filters, labeled, CHROMAFIL Xtra RC, 25 mm, 0.2 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Xtra Hardware Polypropylene (PP) housing with filter membrane Selling unit 100 pieces, 400 pieces Recommended application(s) Suitable for aqueous, polar, hydrophilic as well as mid-polar samples with low particle-load, Suitable for UHPLC, core-shell and HPLC columns packed with particles > 3 µm, GC, SFC Storage temperature RT
	MN729231	Syringe filters, labeled, CHROMAFIL Xtra RC, 25 mm, 0.45 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Xtra Hardware Polypropylene (PP) housing with filter membrane Selling unit 100 pieces, 400 pieces Recommended application(s) General purpose HPLC columns packed with particles > 3 µm, GC, SFC, Suitable for aqueous, polar, hydrophilic as well as mid-polar samples with low particle-load Storage temperature RT
	MN729236	Syringe filters, labeled, CHROMAFIL Xtra RC, 13 mm, 0.2 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Xtra Hardware Polypropylene (PP) housing with filter membrane Recommended application(s) Suitable for aqueous, polar, hydrophilic as well as mid-polar samples with low particle-load, Suitable for UHPLC, core-shell and HPLC columns packed with particles > 3 µm, GC, SFC Storage temperature RT
	MN729237	Syringe filters, labeled, CHROMAFIL Xtra RC, 13 mm, 0.45 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Xtra Hardware Polypropylene (PP) housing with filter membrane Recommended application(s) General purpose HPLC columns packed with particles > 3 µm, GC, SFC, Suitable for aqueous, polar, hydrophilic as well as mid-polar samples with low particle-load Storage temperature RT
	MN729024	Syringe filters, sterile, CHROMAFIL CA, 25 mm, 0.2 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Hardware Polypropylene (PP) housing with filter membrane Recommended application(s) Filtration of water-soluble oligomers and polymers, especially suited for biological macromolecules, Sterile, Suitable for UHPLC, core-shell and HPLC columns packed with particles > 3 µm, GC, SFC Storage temperature RT
	MN729025	Syringe filters, sterile, CHROMAFIL CA, 25 mm, 0.45 µm	Special offer	Add to Cart
Hazardous material No Method Filtration Brand CHROMAFIL Hardware Polypropylene (PP) housing with filter membrane Recommended application(s) Filtration of water-soluble oligomers and polymers, especially suited for biological macromolecules, Sterile, Suitable for HPLC columns packed with particles > 3 µm, GC, SFC Storage temperature RT

<< 12 3 4 5 6 7 8 9 10 >>

Overview

Chemical compatibility of CHROMAFIL membrane and housing material

The chemical compatibility depends on several parameters such as time, pressure, temperature and concentration. In most cases, CHROMAFIL products will have only short contact with a solvent. In these cases they may be used despite of limited compatibility. For example, a PTFE filter with PP housing does not liberate any UV-detectable substances during filtration of 5 mL THF, although PP shows only limited resistance towards THF.

Materials used in CHROMAFIL products

MV = Cellulose mixed ester

CA = Cellulose acetate

RC = Regenerated cellulose

PA = Polyamide

PTFE = Polytetrafluoroethylene

H-PTFE = hydrophilized polytetrafluoroethylene

PVDF = Polyvinylidenedifluoride

PES = Polyethersulfone

PET = Polyester

GF = Glass fiber

IC = Special membrane for Ion chromatography

PP = Polypropylene (housing material)
