LZH409.99.00100 - HACH - Instruments

: Catalog No. LZH409.99.00100

Part No. LZH409.99.00100
Supplier HACH Company

ScrubberMonitor SM100: pH, Conductivity

Net Price

Special offer

Availability

6 weeks

PROPERTIES

Alarm

Low Sample Flow Alarm (Flow < 2 L/min = Alarm)******Potential Freed Contact (Contact Open = Alarm)
Dimensions

W x H x D: 800 × 1000 x 300 mm (31.5” × 39.4” × 11.8”) |Overall dimensions, including flanges, shock absorbers and lifting bolds; W x H x D: 810 x 1135 x 310 mm (31.9” × 44.7” × 12.2”)
Housing Material

Fiberglass-reinforced unsaturated polyester], with door, including viewing window Ingress protection IP56 (corresponds to NEMA 4)
Installation Category

Maritime - [Machinery spaces, control rooms, accommodation, bridge] DNV GL-CG-0339 Class A, except Class B for damp heat exposed by vibrations from surroundings max. 1 mm/speak conform Class A
Model

SM100
Parameter

pH; Conductivity
Range

pH: 0 - 14Cond.: 200 µS/cm - 2000 mS/cm
Storage Conditions

0 - 50 °C (32 - 122 °F); ≤ 95% relative humidity, non-condensing, non-corrosive
Weight

± 55 kg (176 lb)
What's included?

ScrubberMonitor Cabinet withLXV400.99.00121 SC1000 Controller Probe ModuleLXV402.99.00201 SC1000 Controller Display ModuleDPD1P1.99M pHD sc pH SensorD3725E2T.99M 3700-Series Inductive Conductivity Sensor
